Simulate system dynamic response
Sienna\Dyn
Capture the fast dynamics of inverter-based resources after disturbances
Features and Capabilities
Key Features
- Industry-standard models for synchronous machines, automatic voltage regulators, governors, and inverters
- Novel models, including synchronous machines, machine learning surrogates and aggregate distribution systems
- Exchangeable solvers from the scientific machine learning ecosystem
- Separation of models from the integration algorithms coupled with novel numerical techniques
Core Capabilities
- Runs quasi-static, electromagnetic time domain simulations and small signal stability analysis
- Models novel and advanced inverter control methodologies
- Integrates with Sienna\Ops to perform stability analyses of systems with high share of inverter-based resources
- Accelerates electromagnetic analysis of large interconnected systems by over 10×
- Runs electromagnetic simulations employing averaging techniques and modern integration methods
- Provides flexibility in choosing between precision and solution speed for distinct use cases and requirements
- Allows researchers to assess the numerical requirements for new control techniques for inverter-based generation
How It Works
Sienna\Dyn is a modular platform using software packages written in the Julia programming language. All packages are open-source, free to use, and have a command-line interface. See the Documentation for each package's documentation, general installation instructions, and tutorials.
Sienna Documentation
